Semloh 10m Mains lead - Safe 2.5mm Copper Conductors

There has been an influx of cheap, generally Chinese manufactured mains leads, that do not comply to the British Standards, they can have undersized conductors and inferior plugs. This can lead to danger of overheating and possibly fire.

Is Colour important - An Orange cable is the recomended colour for use on Caravan Sites, especially Camping & Caravanning Club and Caravan & Motorhome Club sites. Also lots of commercial site will only allow the use of orange cable.

10m leads are ideal if the service point is close to your caravan or motorhome and also on continental sites where you may be over 25m from the service point, so need to connect a 10m to your 25m lead, if doing this make sure your leads have a 2.5mm conductor and remember to protect the 16amp plug and socket where the leads joint as this will not be waterproof and you should use a suitable method to protect them.

If using a cable coil -Never leave the cable coiled up, as this will cause overheating. lay the cable out as straight as possible and if connecting a 25m and 10m lead protect the connectors from water/rain using a purpose made waterproof cover

What the manufacturer says:-

10m long 230V mains hook-up cable for connecting the inlet on your caravan, campervan, motorhome, boat or other vehicle to the site power supply.  This flexible orange extension lead consists of 3 cores of 2.5mm2 stranded copper cable rated at 20A with PVC insulation and sheathing. It comes pre-fitted with a weatherproof (IP44) 16A plug and socket (coupler), is manufactured to BS6500 and tested to IEE/BS standards.

Specification

• Voltage rating: 200-250V AC
• Current rating of cable: 20A
• Cable size: 3 x 2.5mm2 flexible stranded copper
• Insulation and sheath material: PVC
• Insulation colours: Brown (L), Blue (N), Green/White (E)
• Sheath colour: Orange
